Narrow Pixel Pitch LED Screens

/// LED DIGITAL screens

Experience Unmatched Clarity with Our
Narrow Pixel Pitch LED Screens

Take your digital signage, presentations, and visual displays to the next level with our Narrow Pixel Pitch LED Screens. Designed for environments where high-resolution, detailed visuals are essential, these screens provide incredible image quality with pixel pitches as small as 0.9mm, ensuring crisp, clear images even up close. Our Narrow Pixel Pitch LED Screens are perfect for indoor applications such as control rooms, broadcast studios, high-end retail displays, and corporate environments. With a superior pixel density, they deliver sharp, lifelike visuals that create an immersive experience for your audience, regardless of the viewing distance.

Whether you’re showcasing high-definition videos, graphics, or real-time data, our Narrow Pixel Pitch LED Screens ensure every detail is presented with precision and clarity. The screens offer seamless integration, providing a uniform display with consistent color reproduction, brightness, and contrast.

In addition, these screens are designed with energy efficiency in mind, offering exceptional performance while minimizing power consumption. Their modular design allows for easy installation and scalability, making them an ideal choice for customizable setups or large video walls. Perfect for applications where fine detail is crucial, our Narrow Pixel Pitch LED Screens provide an unparalleled visual experience that elevates your content, impresses your audience, and meets the demands of modern digital environments.

P 1.2

  • LED Chip – Nationstar
  • Driver IC – MBI 5153 / ICN2053
  • Refresh Rate – 3840 Hz
  • Lamp – SMD 1010
  • Pixel Density – 640,000 dots/m²
  • Cabinet Size – 640 mm x 480 mm / 600 mm x 337.5 mm
  • Cabinet Resolution – 512 x 384 pixels  /  480 x 270 pixels
  • Cabinet Material – Magnesium / Aluminum Die-cast
  • Brightness – 800 – 1000 nits
  • Protection Level – IP 57
  • Power Supply – Mean well / G-Energy
  • Maintenance – Front / Back
  • Viewing Angle – 178 H – 160 V
  • Viewing Distance – 1.25M – 100M
  • Control System – Novastar / Colorlight

P 1.5

  • LED Chip – Nationstar
  • Driver IC – MBI 5153 / ICN2053
  • Refresh Rate – 3840 Hz
  • Lamp – SMD 1010
  • Pixel Density – 443,556 dots/m²
  • Cabinet Size – 640 mm x 480 mm / 600 mm x 337.5 mm
  • Cabinet Resolution – 416 x 312 pixels  /  384 x 216 pixels
  • Cabinet Material – Magnesium / Aluminum Die-cast
  • Brightness – 800 – 1000 nits
  • Protection Level – IP 57
  • Power Supply – Mean well / G-Energy
  • Maintenance – Front / Back
  • Viewing Angle – 178 H – 160 V
  • Viewing Distance – 1.5M – 100M
  • Control System – Novastar / Colorlight

P 1.6

  • LED Chip – Nationstar
  • Driver IC – MBI 5153 / ICN2053
  • Refresh Rate – 3840 Hz
  • Lamp – SMD 1010
  • Pixel Density – 362,404 dots/m²
  • Cabinet Size – 640 mm x 480 mm / 600 mm x 337.5 mm
  • Cabinet Resolution – 384 x 288 pixels  /  360 x 200 pixels
  • Cabinet Material – Magnesium / Aluminum Die-cast
  • Brightness – 800 – 1000 nits
  • Protection Level – IP 57
  • Power Supply – Mean well / G-Energy
  • Maintenance – Front / Back
  • Viewing Angle – 178 H – 160 V
  • Viewing Distance – 1.6M – 100M
  • Control System – Novastar / Colorlight

P 1.8

  • LED Chip – Nationstar
  • Driver IC – MBI 5153 / ICN2053
  • Refresh Rate – 3840 Hz
  • Lamp – SMD 1515
  • Pixel Density – 288,400 dots/m²
  • Cabinet Size – 640 mm x 480 mm / 600 mm x 337.5 mm
  • Cabinet Resolution – 344 x 258 pixels  /  320 x 180 pixels
  • Cabinet Material – Magnesium / Aluminum Die-cast
  • Brightness – 800 – 1000 nits
  • Protection Level – IP 57
  • Power Supply – Mean well / G-Energy
  • Maintenance – Front / Back
  • Viewing Angle – 178 H – 160 V
  • Viewing Distance – 1.8M – 100M
  • Control System – Novastar / Colorlight

P 2.5

  • LED Chip – Nationstar
  • Driver IC – MBI 5153 / ICN2053
  • Refresh Rate – 3840 Hz
  • Lamp – SMD 1515
  • Pixel Density – 160,000 dots/m²
  • Cabinet Size – 640 mm x 480 mm
  • Cabinet Resolution – 256 x 192 pixels
  • Cabinet Material – Magnesium / Aluminum Die-cast
  • Brightness – 800 – 1000 nits
  • Protection Level – IP 57
  • Power Supply – Mean well / G-Energy
  • Maintenance – Front / Back
  • Viewing Angle – 178 H – 160 V
  • Viewing Distance – 2.5M – 100M
  • Control System – Novastar / Colorlight
